  • Ultra-compact, mobile bus-powered USB-C compatible audio interface for recording, streaming, podcasting and more
  • Stand-alone functionality lets you take your sound with you
Click here for Features and Specifications
We are here to help! 020 8579 0144
Regular price £149.00 £0.00 Unit price per
In Stock

In Stock

Free next day delivery

On all orders over £100

Frequently bought together:

Keep browsing or just give us a call: 020 8579 0144. We are here to help!

The pocket-sized music studio.

Create a high-end recording studio right at home — or anywhere else — with PreSonus Revelator io44. Whether you want to connect a professional XLR microphone, a guitar, a DJ mixer, or your gaming headset, PreSonus Revelator io44 has all the inputs and outputs you need to record… even a built-in mixer that lets you blend audio from multiple applications. Processing is available on every analog input, so you’ll sound smooth and polished in your performances and recordings.

Guitarists, singers, DJs, and everyone else: you’ll sound great, regardless of if you’re tracking a record or performing live online.

Professional microphones deserve professional amplification.

25 years of studio-grade design experience is inside PreSonus Revelator io44. Your XLR microphones will sound their best thanks to the PreSonus XMAX-L mic preamp with plenty of gain for your professional microphone to capture your voice smoothly, naturally, and distortion-free — and the onboard processing will make your voice stand out. Whether you're recording a vocal or chatting with your followers during a livestream, you’ll be heard loud and clear.

Powerful onboard processing

PreSonus Revelator io44’s onboard processing lets you polish your recordings and streams with one-click ease, thanks to masterfully crafted presets that give you a professional sound with no expertise required. You’ll also find tools to emulate concert hall reverb, AM radio, or otherworldly invaders to completely transform your sound — and of course, you can create and store your own custom presets for later use. And best of all, this processing happens on the PreSonus Revelator io44 itself so your customised sound is available whether you connect PreSonus Revelator io44 to your computer, your tablet, or your phone and won’t use up valuable computer resources when recording or streaming.

Grab audio from anywhere.

PreSonus Revelator io44 features an easy-to-use mixer that lets you blend audio from up to three different applications at once, so you can add backing tracks, Skype calls, and even gameplay quickly and easily — without taxing your computer. An automatic output limiter prevents your stream from distorting. Whether you’re on macOS or Windows, you can create custom mixes of your inputs and your applications and monitor it all at near-zero latency so you can stream and record simultaneously!

Remote control.

Wireless remote control via UC Surface for iPadOS, Windows, and Android™ devices means you get touchscreen control over all of your PreSonus Revelator io44’s features, processing, and mixer features at your fingertips, without having to click away from your stream. Just connect your favourite tablet to the same network as your computer and you’re good to go!

Complete music production software included.

The PreSonus Revelator io44 includes both Studio One Artist production and recording software and the Studio Magic software bundle. Studio One makes it easy to polish your recordings with its lightning-fast drag-and-drop workflow and fully-featured production environment. Studio Magic expands your palette with instruments, plug-ins, and more so you’re ready to hit record right from the start.

Make your own magic.

PreSonus wanted to make sure that their audio interfaces come with everything you need to craft your own mesmerising spells in the studio. That’s why they include Studio One Artist with every audio interface product they make. But in PreSonus' home of Louisiana, they have a word: lagniappe. It means "a little something extra," and it’s in that spirit that PreSonus also include the Studio Magic Suite of software with their audio interface products.

The 2021 Studio Magic is a major step up from the 2020 edition, and includes Ableton Live Lite, tutorials from Melodics, sound libraries from Ghost Hack, 7 virtual instruments, and 9 effects plug-ins in VST, AU, and AAX formats, all unlocked for use inside Studio One Artist, or your DAW of choice, with a retail value of over $1000 (US).

  • Ultra-compact, mobile bus-powered USB-C compatible audio interface for recording, streaming, podcasting and more
  • Stand-alone functionality lets you take your sound with you
  • Integrated mixer lets you blend audio from up to three applications at once
  • Powerful onboard StudioLive processing lets you polish your sound (or completely transform it) with reverb, compression, EQ, and fantastic Voice FX — all without taxing your CPU
  • Connect nearly anything: mics, guitars, headsets, and stereo sources like DJ mixers
  • Professionally crafted Presets make you sound like a pro with a single click. You can also create your own custom presets to share, save, or produce on the go
  • Studio One Artist recording software and Studio Magic software bundle included
  • 96 kHz / 24-bit operation for pristine audio recording
  • 1 digitally controlled, high-headroom, low noise XMAX-L mic preamp for professional results
  • 1 Instrument input (via combo) for guitars and basses
  • 1 TRS 1/8" Stereo Line input for DJ mixers and more
  • Built-in Fat Channel with EQ, Compression, Gate, and Limiter plus Voice Effects and Reverb with 8 easy-to-use factory presets and 6 user presets
  • Access up to 2 presets from PreSonus Revelator io44 for each input via the top-panel button, additional presets are available in Universal Control
  • Custom presets for vocals, broadcast, guitar, and more
  • Share presets with your team
  • Balanced Main Left / Right with independent level control and mute
  • 1 TRRS 1/4" stereo Headset connection (mic in, stereo out)
  • Integrated software mixer for low-latency monitoring, streaming and more
  • 4 dedicated input streams for the Revelator io44 hardware inputs
  • 2 dedicated stereo output streams for monitoring. One dedicated mix for your main outputs and a separate headphone mix sourceable from all available mixes.
  • Two stereo I/O virtual streams for application-to-application recording and playback with loopback options for macOS and Windows
  • macOS, Windows, iOS, and Android compatible
  • Universal Control software mixer, effects editing and hardware control
  • Studio One Artist included
  • Studio Magic software bundle included
Computer system requirements
macOS: version 10.13 or later
200 MB storage space and 4 GB RAM for Universal Control (required for firmware updates)
Available USB port
Windows: Windows 10 or later (64-Bit Only)
200 MB storage space and 4 GB RAM for Universal Control (required for firmware updates and low-latency ASIO support)
Available USB port
Microphone Preamp
Type: XLR female, balanced
Frequency Response: 20 Hz - 20 kHz
(+0.1 dB/-0.3 dB, unity gain, unwtd)
Input Impedance (Balanced): 1.4k ohms
THD+N (1 kHz, -1 dBFS, min gain): 0.005% (1 kHz, -1 dBFS, min gain)
EIN (A-wtd, 150 ohms, max gain): -128 dBu
Gain Control Range: 60 dB
(±1 dB)
Max Input Level: +10 dBu
(±0. dBu, min gain)
Phantom Power: +48 VDC
(10 mA total)
Instrument Input
Type: 1/4" TS female, unbalanced
Frequency Response: 20 Hz - 20 kHz
(+0.1dB/-0.3 dB, unity gain, unwtd)
Input Impedance: 750kohms
Gain Range: 50 dB
Maximum Level: +10 dBu (min. gain)
Line Input (Stereo)
Type: 1/8" TRS female
Maximum Level: +10 dBu
(1 kHz, unity gain, z-balanced)
Frequency Response: 20 Hz - 20 kHz
(+0.1dB/-0.3 dB, unity gain, unwtd)
Gain Range: 40 dB
Main Outputs
Type: 1/4" TRS, Female
Frequency Response: 20 Hz - 20 kHz
(+0.1dB/-0.5 dB, unity gain, unwtd)
THD+N (1 kHz, 0 dBFS, loaded): 0.003%
Maximum Level: +10 dBu
Headphone Output
Type: 1/8" TRRS female
Maximum Power: 30mW/Channel @ 56 ohms
Frequency Response: 20 Hz - 20 kHz
(+0.1dB/-0.3 dB, unity gain, unwtd)
Impedance Working Range: 32 ohms to 300 ohms
Audio Interface
Type: USB-C Compatible USB 2.0
Sample Rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Bit Depth: 24 bit
ADC Converter Range: 96 dB
DAC Converter Range: 96 dB
Hardware: Direct Monitor, Mic Gain, Line Input Trim, Headphone Level, Mute, Preset Select, HPF
Software: Mic Gain, Monitor Mix, Preset Management, Loopback Mixes
Onboard DSP Options: PreSonus StudioLive Fat Channel Processing High Pass Filter, Noise Gate / Expander, 3 Compressor models, 3 EQ models, and Limiter, Reverb
Loopback Mixer: 7 input digital mixer, 3 stereo loopback mixes, stereo monitor mix
Voice Effects: Doubler, Vocoder, Ring Modulator, Comb Filter, Detuner, Delay
Height: 2.3" (58,4 mm)
Depth: 3" (77 mm)
Width: 5.35" (135.9 mm)
Weight: 0.78 lbs (0.35 kg)
